JR DS8711HV High-Voltage Ultra Torque Servo

Overview

JR - JRPS8711HV - DS8711HV High-Voltage Ultra Torque Servo

The 8711HV delivers unheard of power through a new SuperSteel gear train and does it all on a 2S LiPo battery pack-without a regulator!

Add its rugged aluminum case, high voltage motor, legendary JR quality, and true, zero-deadband precision-plus its blistering, 0.12 second speed-and the 8711HV represents a whole new level of big model servo performance.

Battery chemistries such as LiPo, LiIon, and LiFe have become very popular within the RC community. They are the standard for powering electric motors and have also gained popularity as receiver battery packs. The issue is the output voltage of these batteries is higher then the previous standard 4 - and 5-cell NiCd and NiMH packs, 4.8V and 6V respectively. The higher voltage is not an issue with the receivers but can be for the servos. Many servos will not operate at these higher voltages for very long before burning out the motors or electronics.

To get around this issue modelers have had to use a regulator to drop the voltage to an acceptable operating range for their servos, usually around 5 to 6 volts. The addition of a regulator adds a component that, should it fail, can cause the loss of a model.

JR's HV servos are designed with motors and electronics that operate off the direct voltage of a 2-cell LiPo, LiIon, or LiFe receiver battery pack (6.6V to 7.4V nominal voltage). This eliminates the need for a regulator and lowers the chance for a power failure that can cause a catastrophic failure of your model. Also note that the HV servo specs are shown at the higher voltage (7.4V 2S LiPo) but will still operate on a standard 5-cell 6V NiCd, Ni MH battery with a reduction in performance of approximately 10% in speed and torque.

Features

JR - JRPS8711HV - DS8711HV High-Voltage Ultra Torque Servo
Rugged new aluminum case
JR SuperSteel gears for high precision, long wear
Exclusive motor designed for high voltage applications
Outstanding precision combined with outlandish performance

Specifications

JR - JRPS8711HV - DS8711HV High-Voltage Ultra Torque Servo
Size Category: Standard
Type: Digital
Application: Giant-Scale aircraft
Torque: 480 oz/in (2S LiPo battery)
Speed: .12 sec/60 (2S LiPo battery)
Length: 1.58 in
Width: 0.82 in
Height: 1.57 in
Weight: 2.6 oz
Bushing Or Bearing: Bearing
Bearing: Dual
Motor Type: Coreless
Connector Type: JR
Gear Type: Metal
Gear Material: SuperSteel
Voltage: 7.4V (2S LiPo battery)
Deadband: Less than .001ms
