Fly Wing Bell-407 Scale RC Helicopter RTF

Bell-407 Scale RC Helicopter

80CM Large Wingspan Remote Control Helicopter

Product Description

The Bell 407 is a high-performance, single-engine, four-bladed helicopter developed by Bell Helicopter as an evolution of the legendary Bell 206 series. Known for its smooth flight characteristics, improved power, and advanced rotor system, the Bell 407 is widely used in aerial work, law enforcement, and private aviation.

This Bell-407 scale model captures the essence of the real aircraft with a refined design and modern flight technology. It adopts a customised transmission structure, moving away from traditional tail drive systems and utilising a brushless motor direct drive setup for improved efficiency and responsiveness. Equipped with an integrated flight control system and M10 GPS module, it delivers stable hovering and user-friendly handling. With an impressive flight time of up to 20 minutes�"well beyond typical 5�"10 minute models�"it offers a more immersive and extended flying experience.
Key Features

Inspired by the real Bell 407 four-blade helicopter design
GPS navigation with one-key return function
Up to 20 minutes ultra-long flight time
80CM rotor diameter for stable and smooth flight
Brushless motor direct drive system for efficiency and durability
Integrated flight control system for precise handling
M10 GPS positioning module for accurate hovering
Aerodynamic tail design for enhanced flight stability
Detailed scale appearance with refined structural design
Semi-automatic assisted flight mode for easier control
What's Included

Bell-407 Helicopter (pre-assembled and adjusted)
2.4GHz Remote Control Transmitter
Rechargeable Battery
Battery Charger
Spare Parts Kit
Note: Due to packaging requirements, rotor blades need to be attached before first flight.
Technical Specifications

Specification Value
Model Bell-407
Length (without blades) 720mm
Height 235mm
Width 150mm
Weight (excluding battery) 869g
Total Weight 1.2KG
Main Rotor Diameter 810mm
Main Rotor Length (single blade) 370mm
Tail Rotor Diameter 125mm
Technical Details

Motor & Drive System

Main Motor: 3508 Brushless Motor
Tail Drive Motor: Brushless Motor
Motor Main Gear: 13T
Main Drive Gear: 81T
ESC: 60A Electronic Speed Controller
Flight Control System

GPS Mode
3D Manual Mode
Lose Control Return Function
Low Voltage Return Protection
Semi-automatic Assisted Flight
GPS & Navigation

Satellite System: GPS/GLONASS/Galileo
Horizontal Accuracy: ±1.5m (when GPS working well)
Vertical Accuracy: ±0.5m (when GPS working well)
Hovering Precision: Advanced GPS positioning
Control System

Servo: Digital Servo System
Battery: High-capacity rechargeable battery
Flight Time: Up to 20 minutes
Age Recommendation

Suitable for players aged 14 and above

This advanced RC helicopter is ideal for intermediate to advanced pilots, while assisted flight modes make it accessible for supervised beginners.
