MKS X8 HBL380 (0.082 sec/60 - 569.38 oz/in @8.2V)

Product Description

MKS X8 HBL380 High Voltage / High Torque Servo (0.082 sec/60 - 569.38 oz/in @8.2V)

MKS's latest newest high torque, high speed servo with all aluminum cnc machined servo is a monster servo that is a work of art. With up to 569.38 ounces of torque and lightning speed of 0.082 sec/60 degrees these are going to be the servo to beat.

Dead Band 0.0008ms (Default)
Control System +Pulse Width Control
Working Frequence 1520μs / 333hz
Operating Voltage 3.5 ~ 8.4 Volts
Operating Temperature Range -10 to + 60 Degree C
Operating Speed (6V) 0.114 sec/60 degrees at no load
Operating Speed (7.4V) 0.092 sec/60 degrees at no load
Operating Speed (8.4V) 0.082 sec/60 degrees at no load
Stall Torque (6V) 430.51 oz/in (31 kg/cm)
Stall Torque (7.4V) 541.61 oz/in (39 kg/cm)
Stall Torque (8.4V) 569.38 oz/in (41 kg/cm)
Motor Type Brushless Motor
Potentiometer Drive Indirect Drive
Bearing Type 12x8 mm Double bearings
Gear Type Chrome-Titanium alloy gear
Connector Wire Length 24.0 cm (9.4 in)
Dimensions 40 x 20 x 38.5 mm
Weight 73 g

Entire line of MKS servos are available, please call for more info or details
